Copy/Print Mode: Mono 563 W/Color 563 W; Ready Mode: 81 W; Low Power Mode: 51 W; Sleep Mode: 0.7 W
Multi-purpose tray: 100 sheets, 60–220 g/m2 (Banner 129–163 g/m2), A4, A5, A6, B5, B6, Letter, Legal, Custom (70 × 148 to 216 × 356 mm), Banner max. 216 × 1,220 mm; Standard universal paper cassette: 500 sheets, 60–220 g/m2, A4, A5, A6, B5, B6, Letter, Legal, Custom (105 × 148 to 216 × 356 mm).
3,100 sheets
Duplex functionality as standard: 60–220 g/m2, A4, A5, B5, Letter, Legal
Max. 500 sheets face-down with paper full sensor
DP-5100 : RADF 75 pgs (opt) DP-5120: 100 pgs DSDP (opt) DP-5130: DSDP 270 pgs with double feed detection (opt)
93 outline fonts (PCL6), 136 fonts (KPDL 3), 8 fonts ( Windows Vista), 1 (Bitmap font) 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality
All current Windows operating systems, MAC OS X Version 10.9 or higher, Unix, Linux as well as other operating systems on request
25 - 400 % in 1% steps
5 Reductions/5 Enlargements
Text + Photo, Photo, Text, Map, Printed document
Scan-once-copy-many, electronic sort (collate), ID card copy, 2in1, 4in1, auto cassette change, Skip blank page.
Scan-to-email, Scan-to-FTP, Scan-to-SMB 3.0, Scan-to-USB Host, Network TWAIN, WIA, WSD scan
DP-5100 up to 60 ipm; DP-5120 up to 120 ipm; DP-5130 up to 170 ipm.
Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip.
600, 400, 300, 200 dpi (256 grey scales per colour)
TIFF, JPEG, XPS, OpenXPS, PDF (MMR/JPG compression/high compression PDF), Searchable PDF (Option), MS Office file (Option)
Text, photo, text + photo, light text/fine line, optimised for OCR
2 seconds or less
Normal: 8 dot/mm × 3.85 line/mm (200 × 100 dpi) Fine: 8 dot/mm × 7.7 line/mm (200 × 200 dpi) Superfine: 8 dot/mm × 15.4 line/mm (200 × 400 dpi) Ultrafine: 16 dot/mm × 15.4 line/mm (400 × 400 dpi) 600 × 600 dpi Halftone: 256 greyscales
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast
Staple cartridge 3 x 5,000
Toner cyan for 12,000 pages. Average continuous toner yield in accordance with 5 % coverage (A4).
Toner black for 18,000 pages. Average continuous toner yield in accordance with 5 % coverage (A4).
Toner magenta for 12,000 pages. Average continuous toner yield in accordance with 5 % coverage (A4).
Toner yellow for 12,000 pages. Average continuous toner yield in accordance with 5 % coverage (A4).
Waste Toner Bottle: 44,000 sheets (in accordance with 5% coverage b/w:colour=7:3)
Wooden desk (high)
Wooden desk (low)
Metal desk (high)
Metal desk (low)
Enables the use of the ID card user authentication system
To integrate the USB IC Card Reader
320 GB HDD hard disc for easy document management
Direct WiFi Interface
Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT
Wi-Fi Card (802.11b/g/n)
Allows you to send or receive faxes over the Internet without a telephone line
ThinPrint Kit: enables printing under ThinPrint
Additional Printer Emulations (IBM Proprinter, LinePrinter, EPSON LQ-850)
Simplifies authentication on the system
