square-540x540.ECOSYS-PA4500x

ECOSYS PA4500x

The ECOSYS PA4500x is a powerful printer embedded with high-level security features. The rapid speed of up to 45 pages per minute contributes to the enhanced productivity of smaller workgroups. Thanks to long-life components and low energy consumption, leaves a smaller environmental footprint.

  • Data overwrite and encryption, Trusted Platform Module, Secure Boot and Run Time Integrity Check, S/MIME and TLS 1.3
  • Up to 6 different paper inputs max. 2,600 sheet capacity
  • Strenghen affinity with Microsoft Universal Print
  • Optional SSD hard disk with Data Security Kit
  • Environmentally friendly: long-life components, low energy consumption
Engine speed
Engine speed

Up to 45 pages A4 per minute. Duplex print speed: up to 22.5 page per minute, A4.

Resolution
Resolution

1200 x 1200 dpi

Dimensions (W x D x H)
Dimensions (W x D x H)

W380 × D410 × H285mm (Value without projections), W390 × D410 × H308mm (Value with projections)

Warranty
Warranty

2-year warranty as standard **KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions. Up to 3-year on-site warranty extensions available for product and options.

ECOSYS makes your office more sustainable and efficient

Kyocera solutions always work with the environment in mind, but the ECOSYS range do this more than any other product on the market.

  • ECOSYS PA4500x drivers
  • ECOSYS PA4500x documentation
  • ECOSYS PA4500x software

Main Specifications

General
  • General
  • Paper handling
  • Print
square-540x540.ECOSYS-PA4500x
General type
Monochrome printer for A4 format
Engine speed
Up to 45 pages A4 per minute. Duplex print speed: up to 22.5 page per minute, A4.
Warm-up time
Approx. 16 seconds or less from power on
Power consumption
Print - mode: 605.5 W, Sleep mode: 0.5 W, Ready - mode: 8.4 W
Warranty
2-year warranty as standard **KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions. Up to 3-year on-site warranty extensions available for product and options.
Input capacity
100-sheet multi-purpose tray: MP tray: 60 - 220g/m2, A4, A5, A6, B5, Letter, Legal, Custom (70 x 148 - 216 x 356 mm), Banner paper up to 915 mm 500-sheet universal paper cassette: : 60 - 120g/m2, A4, A5, B5, Letter, Legal, Custom (140 x 210 - 216 x 356 mm)
Max. input capacity with options
2,600 sheets
Duplex unit
Duplex functionality as standard: Double sided printing: A4, A5, B5, Letter, Legal, Custom (140 x 210 mm - 216 x 356 mm), 60 - 120g/m2
Max. output capacity
250-sheet-face-down with paper full sensor
Processor
ARM Cortex-A53 Dual core 1.4GHz
Fonts
93 outline fonts (PCL6/KPDL 3), 8 fonts (Windows), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Features
PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, Encrypted PDF Direct Print
Applicable OS
All current Windows operating systems, Mac OS X Version 10.9 or higher, UNIX LINUX, as well as other operating systems on request

Options and Consumables

Paper handling Options
  • Paper handling Options
  • Options

CA-3100
Caster stand

IB-32B
Parallel IEEE1284 interface kit

IB-50
Gigabit-Ethernet board 10BaseT/100BaseTX/1000BaseT

IB-51
Wireless LAN Interface (802.11b/g/n)

KYOmulticode SD 3
Contains all the functionalities of PCL Barcode Flash plus Unicode font “Andale Mono World Type“ which allows the user to print Asian fonts (Japanese, Korean, current and traditional Chinese)

PCL Barcode SD
Adds additional one- and two-dimensional barcodes to the KYOCERA device (as well as the resident and machine-readable fonts OCR-A, OCR-B)

UG-33
ThinPrint support

USB IC Card Reader + Card Authentication Kit (B)
Support for various authentication keys available
